NSA Codebreakers 2024

Jan 20, 2025

Task 1

Aaliyah is showing you how Intelligence Analysts work. She pulls up a piece of intelligence she thought was interesting. It shows that APTs are interested in acquiring hardware tokens used for accessing DIB networks. Those are generally controlled items, how could the APT get a hold of one of those?

DoD sometimes sends copies of procurement records for controlled items to the NSA for analysis. Aaliyah pulls up the records but realizes it’s in a file format she’s not familiar with. Can you help her look for anything suspicious?

If DIB companies are being actively targeted by an adversary the NSA needs to know about it so they can help mitigate the threat. Help Aaliyah determine the outlying activity in the dataset given

Downloads: DoD procurement records (shipping.db) Prompt: Provide the order id associated with the order most likely to be fraudulent.

$file shipped.db

Tried to open with OpenSQLite browser but couldn’t open it. Shows encrypted.
Then found out it is not an encrypted file:

$fcrackzip -v -u -D -p /usr/share/wordlists/rockyou.txt shipping.db
'mimetype' is not encrypted, skipping
'Configurations2/toolpanel/' is not encrypted, skipping
'Configurations2/progressbar/' is not encrypted, skipping
'Configurations2/statusbar/' is not encrypted, skipping
'Configurations2/toolbar/' is not encrypted, skipping
'Configurations2/floater/' is not encrypted, skipping
'Configurations2/popupmenu/' is not encrypted, skipping
'Configurations2/menubar/' is not encrypted, skipping
'manifest.rdf' is not encrypted, skipping
found id 6ecd93cd, 'shipping.db' is not a zipfile ver 2.xx, skipping
no usable files found

After Unzipping, tried to view content of content.xml: All Gibbrish
Tried to reconstruct it in readable format:
```
$zip -r ../files.odt *
```
Word & Libreoffice don’t show good format, not readable and cannot be analyzed
Reconstructing to Sqlite file using python script.
Finally reconstructed after trial and error.
Found Guardian Armamenet a suspicious company from Thumbnails.png after Googling all companies names

Random Entry for a different addresss at No:899 which is suspicous

Boom Flag

Task 1 Badge

Task 2

Having contacted the NSA liaison at the FBI, you learn that a facility at this address is already on a FBI watchlist for suspected criminal activity. With this tip, the FBI acquires a warrant and raids the location.

Inside they find the empty boxes of programmable OTP tokens, but the location appears to be abandoned. We’re concerned about what this APT is up to! These hardware tokens are used to secure networks used by Defense Industrial Base companies that produce critical military hardware.

The FBI sends the NSA a cache of other equipment found at the site. It is quickly assigned to an NSA forensics team. Your friend Barry enrolled in the Intrusion Analyst Skill Development Program and is touring with that team, so you message him to get the scoop. Barry tells you that a bunch of hard drives came back with the equipment, but most appear to be securely wiped. He managed to find a drive containing what might be some backups that they forgot to destroy, though he doesn’t immediately recognize the data. Eager to help, you ask him to send you a zip containing a copy of the supposed backup files so that you can take a look at it.

If we could recover files from the drives, it might tell us what the APT is up to. Provide a list of unique SHA256 hashes of all files you were able to find from the backups.

Downloads: disk backups (archive.tar.bz2) Prompt: Provide your list of SHA256 hashes

Create ZFS Pool on Ubuntu using following commands:

$lsblk
$sudo fallocate -l 1G /tmp/zfs-disk.img
$sudo losetup -fP /tmp/zfs-disk.img
$losetup -a
$lsblk
$sudo zpool create nkfipool /dev/loop46
$sudo zfs create nkfipool/rjfs
$zfs list -t snapshot
$zpool list

If directory is hidden:

$sudo zfs get snapdir nkfipool/rjfs
$sudo zfs set snapdir=visible nkfipool/rjfs
$sudo zfs get snapdir nkfipool/rjfs

Info on Pool:

$sudo zdb -vvv nkfipool/rjfs

Manually Recover each Snapshot SEQUENTIALLY using source GUID & Destination GUID:

View GUID:

$ for f in *; do file "$f"; done | cut -d':' -f1,4,5 | column -t -s ':'
$ sudo zfs receive nkfipool/rjfs > logseq24006643128753-i

Check directory of each recovered snapshot: :/nkfipool/rjfs/planning/pages

$ ls
 contents.md        'Elliptic curve recovery.md'   LLM.md   'token generation.md'  'ZFS snapshots.md'
'CUDA elliptic.md'   golang.md                     todo.md   tools.md

Do checksum of each file

Write Script to do checksum of each file, then print it:

#!/bin/bash

# Base directory where all logseq directories are stored
BASE_DIR="/nkfipool/rjfs/.zfs/snapshot"

# List of logseq directories
LOGSEQ_DIRS=(
    "logseq11079254764090"
    "logseq11652828730004"
    "logseq11865316111135"
    "logseq1275510227140"
    "logseq169607977607"
    "logseq1838778124435"
    "logseq18584850428477"
    "logseq211821980113211"
    "logseq24006643128753"
    "logseq259372600032543"
    "logseq263292687127458"
    "logseq269718728817"
    "logseq27077118912783"
    "logseq30280209123973"
    "logseq307981931423438"
    "logseq4015160425167"
    "logseq73041633518013"
    "logseq77311709316810"
    "logseq81871640320073"
    "logseq98931947620095"
)

# Iterate through each logseq directory
for logseq_dir in "${LOGSEQ_DIRS[@]}"; do
    # Directory containing files
    PAGES_DIR="$BASE_DIR/$logseq_dir/planning/pages"

    # Check if the directory exists
    if [ -d "$PAGES_DIR" ]; then
        #echo "Processing files in $PAGES_DIR"
	echo ""

        # Iterate through each file in the pages directory
        for file in "$PAGES_DIR"/*; do
            if [ -f "$file" ]; then
                # Print the SHA256 checksum of the file
                sha256sum "$file"
            fi
        done
    else
        #echo "Directory $PAGES_DIR does not exist or is inaccessible."
	echo ""
    fi
done

Boom You’ve got all checksums

Task 2 Badge
